AWC 900 TWO-COLOR CHOCOLATE FILLING MACHINE
Technical Specifications
- The surfaces in contact with food which are used in the machine are made of AISI 304 stainless material,
- The conveyor system for conveying the jars is speed controlled and the conveyor belt is made of polyethylene material,
- The chocolate filling nozzles are made of 7075 aluminum,
- The machine has a two-color chocolate feeding chamber with a capacity of 30 LT,
- The machine system and nozzles are completely fed with hot water,
- The machne can produce hot water in its system, 4.500 watt resistor is used in hot water system,
- Our machine has volumetric system and the weight is set manually, Black and White chocolate are given in the same weight,
- The system of chocolate suction, discharge and diverter valves is pneumatic system,
- The machine has a 50 Lt air supply tank,
- The pneumatic system operates in the range of 6-8 bars,
- It has a failure warning when the supply air pressure drops,
- The chocolate transfer hoses of the nozzle are made of food grade material and the product used is TSE certified,
- The "Autonics" control screen is used to set the machine's heat.
- The fuse contactors and motor protection relays used in the machine are from "SIEMENS",
- The speed control device used in the conveyor belt system is from "DELTA",
- The total electric power of the machine: 5.5 Kw,
- The weight of the machine: 340 kg
